VSH Shurjoint drain elbow (2 x groove)

VSH Shurjoint drain elbow (2 x groove)

group: 7110DR

The VSH Shurjoint  Model 7110DR is a grooved-end ductile iron cast elbow with an integral 1” NPT or BSP drain. The 7110DR was primarily designed for, but not limited to, use on fire protection stand­pipes.

applications

no applications available

solutions

no solutions available

approvals

CRN

CRN

FM

FM

UL

UL

ULc

ULc

show all
show less
code size weight dimensions packaging gtin
1110D0020001 60.3 w/ 1 FNPT orange 0.99 kg 113x60x113 mm
1110D0025001 73 w/ 1 FNPT orange 1.3 kg 132x73x132 mm
1110D0030001 88.9 w/ 1 FNPT orange 2.1 kg 152x89x152 mm
1110D0030002 88.9 w/ 1 Rc red 2.1 kg 152x89x152 mm
1110D0030003 88.9 w/ 1 FNPT galvanized 2.1 kg 152x89x152 mm
1110D0045001 114.3 w/ 1 FNPT orange 3 kg 184x114x184 mm
1110D0045003 114.3 w/ 1 FNPT galvanized 3 kg 184x114x184 mm
1110D0065001 168.3 w/ 1 FNPT orange 6.06 kg 249x168x249 mm
1110D0085001 219.1 w/ 1 FNPT orange 11.6 kg 307x219x307 mm
art. No size d1 DN1 l1 d2 DN2 l2 angle
1110D0020001 60.3 w/ 1 FNPT orange 60.3 DN50 83 60.3 DN50 83 90
1110D0025001 73 w/ 1 FNPT orange 73.0 DN65 95 73.0 DN65 95 90
1110D0030001 88.9 w/ 1 FNPT orange 88.9 DN80 108 88.9 DN80 108 90
1110D0030002 88.9 w/ 1 Rc red 88.9 DN80 108 88.9 DN80 108 90
1110D0030003 88.9 w/ 1 FNPT galvanized 88.9 DN80 108 88.9 DN80 108 90
1110D0045001 114.3 w/ 1 FNPT orange 114.3 DN100 127 114.3 DN100 127 90
1110D0045003 114.3 w/ 1 FNPT galvanized 114.3 DN100 127 114.3 DN100 127 90
1110D0065001 168.3 w/ 1 FNPT orange 168.3 DN150 165 168.3 DN150 165 90
1110D0085001 219.1 w/ 1 FNPT orange 219.1 DN200 197 219.1 DN200 197 90
drawing for product
color silver, red, orange
materials cast iron (ASTM A536 65-45-12)
finishing galvanised, varnished
manufacturer Shurjoint
shape Elbow (90º)
connection type groove (fitting)
product group fittings
ETIM class EC003024 Fitting with 2 connections
country of origin Taiwan
brand VSH
series Shurjoint
type 7110DR
label value
ETIM class EC003024 Fitting with 2 connections
Material connection 1 Cast iron
Material connection 2 Cast iron
Shape Bend
Bend angle 90°
Reducing No
Eccentric No
System specific No
Connection 1 Groove
Connection 2 Groove
With buffer stud No
With sealing rings/gaskets No
Capped No
With connection indicator No
With drain valve Yes
With de-aerator No
LPCB quality mark No
VdS quality mark No
DVGW quality mark for gas No
DVGW quality mark for water No
Certified according to NF 545 No
KIWA certified No
Gastec QA mark No
KOMO certified No
Gastec QA - AR 214 (H2) No
