VSH Shurjoint hose nipple

VSH Shurjoint hose nipple

56

The VSH Shurjoint Model 56 hose nipple allows for a direct connection with rubber or plastic hoses.

code size weight dimensions packaging gtin
100560010001 33.4 (DN25) black, fab. 0.18 kg 33x33x84 mm
100560015001 48.3 (DN40) black 0.34 kg 102x48x48 mm
100560020001 60.3 (DN50) black 0.55 kg 118x60x60 mm
100560025001 73 (DN65) black 1.04 kg 140x73x73 mm
100560030001 88.9 (DN80) black 1.44 kg 156x89x89 mm
100560045001 114.3 (DN100) black 2.51 kg 184x114x114 mm
100560055001 141.3 (DN125) black 3.7 kg 248x141x141 mm
100560065001 168.3 (DN150) black 6.57 kg 280x168x168 mm
100560085001 219.1 (DN200) black 11.08 kg 318x219x219 mm
art. No size d1 DN1 l1 d2 DN2 l2
100560010001 33.4 (DN25) black, fab.
100560015001 48.3 (DN40) black 48.3 DN40 51 48.3 DN40 51
100560020001 60.3 (DN50) black 60.3 DN50 59 60.3 DN50 59
100560025001 73 (DN65) black 73.0 DN65 70 73.0 DN65 70
100560030001 88.9 (DN80) black 88.9 DN80 78 88.9 DN80 78
100560045001 114.3 (DN100) black 114.3 DN100 92 114.3 DN100 92
100560055001 141.3 (DN125) black 141.3 DN125 124 141.3 DN125 124
100560065001 168.3 (DN150) black 168.3 DN150 140 168.3 DN150 140
100560085001 219.1 (DN200) black 219.1 DN200 159 219.1 DN200 159
see above for the diagram with these dimensions.
color black
materials ductile iron (ASTM A536 65-45-12)
finishing none
manufacturer Shurjoint
shape straight
connection type groove (fitting), hose connector
product group fittings
country of origin Taiwan
brand VSH
series Shurjoint
type 56
