VSH Shurjoint stainless steel universal flange nipple (groove x flange)

code

size

dimensions

weight

packaging

gtin

code

1SS800020001

size

2" 304

dimensions

64x165x165 mm

weight

2 kg

packaging

-

gtin

-

code

1SS800020002

size

2" 316

dimensions

64x165x165 mm

weight

2 kg

packaging

-

gtin

-

code

1SS800025001

size

2 1/2" 304

dimensions

76x185x185 mm

weight

2.9 kg

packaging

-

gtin

-

code

1SS800025002

size

2 1/2" 316

dimensions

76x185x185 mm

weight

2.9 kg

packaging

-

gtin

-

code

1SS800029001

size

76.1 (DN65) 304

dimensions

76x185x185 mm

weight

2.98 kg

packaging

-

gtin

04710574446871

code

1SS800029002

size

76.1 (DN65) 316

dimensions

76x185x185 mm

weight

2.98 kg

packaging

-

gtin

-

code

1SS800030001

size

3" 304

dimensions

75x200x200 mm

weight

3.38 kg

packaging

-

gtin

-

code

1SS800030002

size

3" 316

dimensions

75x200x200 mm

weight

3.38 kg

packaging

-

gtin

-

code

1SS800045001

size

4" 304

dimensions

75x225x225 mm

weight

3.91 kg

packaging

-

gtin

00670750444692

code

1SS800045002

size

4" 316

dimensions

75x225x225 mm

weight

3.91 kg

packaging

-

gtin

-

code

1SS800052001

size

139.7 (DN125) 304

dimensions

75x254x254 mm

weight

6.74 kg

packaging

-

gtin

-

code

1SS800052002

size

139.7 (DN125) 316

dimensions

75x254x254 mm

weight

6.74 kg

packaging

-

gtin

-

code

1SS800055001

size

5" 304

dimensions

75x254x254 mm

weight

6.65 kg

packaging

-

gtin

-

code

1SS800055002

size

5" 316

dimensions

75x254x254 mm

weight

6.65 kg

packaging

-

gtin

-

code

1SS800062001

size

165.1 (DN150) 304

dimensions

75x272x272 mm

weight

6.8 kg

packaging

-

gtin

-

code

1SS800062002

size

165.1 (DN150) 316

dimensions

75x272x272 mm

weight

6.8 kg

packaging

-

gtin

-

code

1SS800065001

size

6" 304

dimensions

75x272x272 mm

weight

6.86 kg

packaging

-

gtin

00670750444715

code

1SS800065002

size

6" 316

dimensions

75x272x272 mm

weight

6.86 kg

packaging

-

gtin

-

code

1SS800080001

size

216.3 304

dimensions

102x343x343 mm

weight

13.98 kg

packaging

-

gtin

-

code

1SS800080002

size

216.3 316

dimensions

102x343x343 mm

weight

13.98 kg

packaging

-

gtin

-

code

1SS800085001

size

8" 304

dimensions

102x343x343 mm

weight

14.45 kg

packaging

-

gtin

-

code

1SS800085002

size

8" 316

dimensions

102x343x343 mm

weight

14.45 kg

packaging

-

gtin

-

code

1SS8000A1001

size

10" 304

dimensions

100x406x406 mm

weight

21.32 kg

packaging

-

gtin

-

code

1SS8000A1002

size

10" 316

dimensions

100x406x406 mm

weight

21.32 kg

packaging

-

gtin

-

code

1SS8000A3001

size

12" 304

dimensions

113x483x483 mm

weight

30.5 kg

packaging

-

gtin

-

code

1SS8000A3002

size

12" 316

dimensions

113x483x483 mm

weight

30.5 kg

packaging

-

gtin

-

code

size

d1

DN1

l1

d2

DN2

l2

code

1SS800020001

size

2" 304

d1

60.3

DN1

2"

l1

48

d2

165.0

DN2

2"

l2

16

code

1SS800020002

size

2" 316

d1

60.3

DN1

2"

l1

48

d2

165.0

DN2

2"

l2

16

code

1SS800025001

size

2 1/2" 304

d1

73.0

DN1

2-1/2"

l1

60

d2

185.0

DN2

2-1/2"

l2

16

code

1SS800025002

size

2 1/2" 316

d1

73.0

DN1

2-1/2"

l1

60

d2

185.0

DN2

2-1/2"

l2

16

code

1SS800029001

size

76.1 (DN65) 304

d1

76.1

DN1

2-1/2"

l1

60

d2

185.0

DN2

2-1/2"

l2

16

code

1SS800029002

size

76.1 (DN65) 316

d1

76.1

DN1

2-1/2"

l1

60

d2

185.0

DN2

2-1/2"

l2

16

code

1SS800030001

size

3" 304

d1

88.9

DN1

3"

l1

59

d2

200.0

DN2

3"

l2

16

code

1SS800030002

size

3" 316

d1

88.9

DN1

3"

l1

59

d2

200.0

DN2

3"

l2

16

code

1SS800045001

size

4" 304

d1

114.3

DN1

4"

l1

59

d2

225.0

DN2

4"

l2

16

code

1SS800045002

size

4" 316

d1

114.3

DN1

4"

l1

59

d2

225.0

DN2

4"

l2

16

code

1SS800052001

size

139.7 (DN125) 304

d1

139.7

DN1

5"

l1

59

d2

254.0

DN2

5"

l2

16

code

1SS800052002

size

139.7 (DN125) 316

d1

139.7

DN1

5"

l1

59

d2

254.0

DN2

5"

l2

16

code

1SS800055001

size

5" 304

d1

141.3

DN1

5"

l1

59

d2

254.0

DN2

5"

l2

22

code

1SS800055002

size

5" 316

d1

141.3

DN1

5"

l1

59

d2

254.0

DN2

5"

l2

22

code

1SS800062001

size

165.1 (DN150) 304

d1

165.1

DN1

6"

l1

59

d2

272.0

DN2

6"

l2

16

code

1SS800062002

size

165.1 (DN150) 316

d1

165.1

DN1

6"

l1

59

d2

272.0

DN2

6"

l2

16

code

1SS800065001

size

6" 304

d1

168.3

DN1

6"

l1

59

d2

272.0

DN2

6"

l2

16

code

1SS800065002

size

6" 316

d1

168.3

DN1

6"

l1

59

d2

272.0

DN2

6"

l2

16

code

1SS800080001

size

216.3 304

d1

216.3

DN1

8"

l1

80

d2

343.0

DN2

8"

l2

22

code

1SS800080002

size

216.3 316

d1

216.3

DN1

8"

l1

80

d2

343.0

DN2

8"

l2

22

code

1SS800085001

size

8" 304

d1

219.1

DN1

8"

l1

80

d2

343.0

DN2

8"

l2

22

code

1SS800085002

size

8" 316

d1

219.1

DN1

8"

l1

80

d2

343.0

DN2

8"

l2

22

code

1SS8000A1001

size

10" 304

d1

273.0

DN1

10"

l1

70

d2

406.0

DN2

10"

l2

30

code

1SS8000A1002

size

10" 316

d1

273.0

DN1

10"

l1

70

d2

406.0

DN2

10"

l2

30

code

1SS8000A3001

size

12" 304

d1

323.9

DN1

12"

l1

81

d2

483.0

DN2

12"

l2

32

code

1SS8000A3002

size

12" 316

d1

323.9

DN1

12"

l1

81

d2

483.0

DN2

12"

l2

32

product info

item

VSH Shurjoint stainless steel universal flange nipple (groove x flange)

item number with GTIN

SS-80

manufacturer

Shurjoint

weight

30.5 kg

dimensions

113x483x483 mm

characteristics

color

silver

materials

stainless steel (Stainless steel 304 (1.4301), Stainless steel 316 (1.4401))

finishing

none

connection type

groove (fitting), flange

general

product group

fittingen (demountable)

ETIM class

EC003024 Fitting with 2 connections

country of origin

Taiwan

brand

VSH

series

Shurjoint Stainless Steel

type

SS-80

image | jpg

SS-80

diagram | png

Diagram

datasheet | pdf

Datasheet

installation- & maintenance document | pdf

VSH Shurjoint Installation Handbook

certificate | pdf

FM Pipe Fittings

certificate | pdf

UL Drinking Water System Components

certificate | pdf

UL Fittings, Grooved and Plain End

certificate | pdf

ULc Fittings, Grooved and Plain End

certificate | pdf

VSH Shurjoint CSTBat

label

value

label

etim-class

value

EC003024 Fitting with 2 connections

label

Material connection 1

value

Stainless steel

label

Surface protection connection 1

value

Untreated

label

Surface treatment connection 1

value

Untreated

label

Material connection 2

value

Stainless steel

label

Surface protection connection 2

value

Untreated

label

Surface treatment connection 2

value

Untreated

label

Shape

value

Straight

label

Reducing

value

No

label

Eccentric

value

No

label

System specific

value

Yes

label

Connection 1

value

Groove

label

Connection 2

value

Flange

label

Main colour fitting

value

Grey

label

With buffer stud

value

No

label

With sealing rings/gaskets

value

No

label

Capped

value

No

label

With connection indicator

value

No

label

With drain valve

value

No

label

With de-aerator

value

No

label

LPCB quality mark

value

No

label

VdS quality mark

value

No

label

DVGW quality mark for gas

value

No

label

DVGW quality mark for water

value

No

label

Certified according to NF 545

value

No

label

KIWA certified

value

No

label

Gastec QA mark

value

No

label

KOMO certified

value

No

label

Gastec QA - AR 214 (H2)

value

No
