group: 812
item: 108121005001
VSH Shurjoint grooved pipe systems consist of a wide range of groove couplings, fittings and valves for heating, compressed air and industry. VSH Shurjoint is less labor intensive, safer, cleaner and delivers consistent connection quality.
no applications available
no segments available
CRN
FM
UL
ULc
color
black
materials
cast iron (ASTM A536 65-45-12)
finishing
varnished
manufacturer
Shurjoint
shape
Elbow (90º)
connection type
FPT - female thread conical (NPT)
product group
fittings
ETIM class
EC003024 Fitting with 2 connections
country of origin
Taiwan
brand
VSH
series
Shurjoint Threaded
type
812
item
VSH Shurjoint Threaded 90° reducing elbow 1" x1/2" FNPT black
item number
108121005001
product number
108121005001
item group
812 - VSH Shurjoint threaded 90° reducing elbow (2 x female thread)
size
1 x1/2 FNPT black
weight
0.21 kg
dimensions
52x33x43 mm
label
value
label
d1
value
33.4
label
DN1
value
DN25
label
l1
value
32
label
d2
value
21.3
label
DN2
value
DN15
label
l2
value
35
label
angle
value
90
label
value
label
ETIM class
label
Material connection 1
value
Cast iron
label
Surface protection connection 1
value
Lacquered
label
Material connection 2
value
Cast iron
label
Surface protection connection 2
value
Lacquered
label
Shape
value
Bend
label
Bend angle
value
90°
label
Reducing
value
No
label
Eccentric
value
No
label
System specific
value
No
label
Nominal diameter connection 1
value
DN 25
label
Outer pipe diameter connection 1
value
33.4mm
label
Outer pipe diameter connection 1 (imperial)
value
1.31"
label
Connection 1
value
Internal thread conical (NPT)
label
Nominal diameter connection 2
value
DN 15
label
Outer pipe diameter connection 2
value
21.3mm
label
Outer pipe diameter connection 2 (imperial)
value
0.84"
label
Connection 2
value
Internal thread conical (NPT)
label
Main colour fitting
value
Black
label
With buffer stud
value
No
label
Length
value
51.7mm
label
Length of connection 1
value
32mm
label
Length of connection 1 (imperial)
value
1.26"
label
Length of connection 2
value
35mm
label
Length of connection 2 (imperial)
value
1.38"
label
With sealing rings/gaskets
value
No
label
Capped
value
No
label
With connection indicator
value
No
label
With drain valve
value
No
label
With de-aerator
value
No
label
FM quality mark
value
Yes
label
LPCB quality mark
value
No
label
ULC quality mark
value
Yes
label
UL quality mark
value
Yes
label
VdS quality mark
value
No
label
DVGW quality mark for gas
value
No
label
DVGW quality mark for water
value
No
label
Certified according to NF 545
value
No
label
KIWA certified
value
No
label
Gastec QA mark
value
No
label
KOMO certified
value
No
label
Gastec QA - AR 214 (H2)
value
No
