item: 107232510001
sprinkler
dry fire main
fire protection
commercial building
industry
CRN
FM
LPCB
QB (CSTBat)
UL
ULc
VdS
label
value
label
d1
value
33.4
label
DN1
value
DN25
label
l1
value
70
label
z1
value
61
label
d2
value
30.0
color
orange
materials
cast iron (ASTM A536 65-45-12)
finishing
varnished
shape
Tapping saddle
connection type
FPT - female thread conical (NPT), hole
sealing
EPDM
product group
fittings (demountable)
ETIM class
EC011014 Broaching saddle
country of origin
Taiwan
brand
VSH
series
Shurjoint
type
723
item
VSH Shurjoint fire sprinkler saddle-let MF 76.1xFNPT1 orange
item number
107232510001
product number
107232510001
manufacturer
Shurjoint
item group
723 - VSH Shurjoint saddle-let (female thread)
size
76.1xFNPT1 orange
weight
0.45 kg
dimensions
57x97x140 mm
max operating pressure liquid
20 bar
min. medium temperature
-34 °C
max medium temperature
110 °C
image | png
723-Combi
diagram | png
Diagram
submittal sheet | pdf
Datasheet
installation- & maintenance document | pdf
VSH Shurjoint Installation Handbook
certifications | pdf
certifications | pdf
FM
certifications | pdf
LPCB
link to sheet | pdf
MSDS_Shurjoint_Orange_paint
certifications | pdf
UL
certifications | pdf
ULc
certifications | pdf
VSH Shurjoint CSTBat
certifications | pdf
VdS
label
value
label
ETIM class
label
Material
value
Cast iron
label
Material inlay
value
Ethylene-propylene diene monomer rubber (EPDM)
label
Surface protection
value
Lacquered
label
Suitable for pipe diameter
value
DN 65
label
Nominal diameter
value
DN 25
label
Outer pipe diameter
value
33.4mm
label
Outer pipe diameter (imperial)
value
1.31"
label
Connection
value
Internal thread conical (NPT)
label
Max. operating pressure at 20 °C
value
20bar
label
Max. operating pressure at 20 °C (imperial)
value
290.08psi
label
Medium temperature (continuous)
value
-34°C - 110°C
label
Medium temperature (continuous) (imperial)
value
-29.2°F - 230°F
label
Width
value
57mm
label
Length of connection 1
value
70mm
label
Length of connection 1 (imperial)
value
2.76"
label
Working length connection 1
value
61mm
label
Working length connection 1 (imperial)
value
2.4"
label
Working length connection 3
value
38.5mm
label
Working length connection 3 (imperial)
value
1.52"
label
VdS quality mark
value
Yes
label
KIWA certified
value
No
label
Gastec QA mark
value
No
label
Gastec QA - AR 214 (H2)
value
No
