1043A0020003
type 7043E
7043E is the designation for model 7043 with a Grade E EPDM gasket. The VSH Shurjoint Model 7043 flange adapter allows for a direct connection with ANSI Class 300 flanges. The specially designed gasket enables the transition from a grooved system to a flanged system or component with this single flange. 2” through 8” Model 7043 flange adapters are supplied hinged as a single assembly, while larger sizes are supplied with separate segments. The Model 7043 flange adapters are comprised of two identical ductile iron segments complete with an EPDM gasket and two pairs of bolts and nuts. The flange segments are painted black.
The Model 7043 flange adapter has been designed with small projections on the outside face of the flange for mating with 1.6 mm raised face flanges. For mating with flat-face flanges these projections must be removed, this can be accomplished with a grinder or other tool.
approvals
| color | silver |
|---|---|
| materials | cast iron (ASTM A536 65-45-12) |
| finishing | galvanised |
| manufacturer | Shurjoint |
| shape | straight |
| connection type | groove (coupling), flange |
| sealing | EPDM |
| item | VSH Shurjoint ANSI 300 flange adapter 60.3 (2) galvanized |
|---|---|
| item number | 1043A0020003 |
| product number | 1043A0020003 |
| item group | 7043E - VSH Shurjoint A300 flange adapter, EPDM gasket |
| size | 60.3 (DN50) A300 galvanized |
| weight | 2.35 kg |
| dimensions | 24x165x165 mm |
| product group | fittings |
|---|---|
| ETIM class | EC003024 Fitting with 2 connections |
| country of origin | Taiwan |
| brand | VSH |
| series | Shurjoint |
| type | 7043E |
| min. medium temperature | -34 °C |
|---|---|
| max medium temperature | 110 °C |
| label | value |
|---|---|
| d1 | 60.3 |
| DN1 | DN50 |
| l1 | 24 |
| d2 | 60.3 |
| DN2 | DN50 |
| n2 | 8 |
| k2 | 120.5 |
| d2-2 | 19 |
| D2 | 127 |
| label | value |
|---|---|
| ETIM class | EC003024 Fitting with 2 connections |
| Material connection 1 | Cast iron |
| Surface protection connection 1 | Galvanic/electrolytic zinc plated |
| Material connection 2 | Cast iron |
| Surface protection connection 2 | Galvanic/electrolytic zinc plated |
| Shape | Straight |
| Model | 2-part |
| Reducing | No |
| Eccentric | No |
| System specific | No |
| Nominal diameter connection 1 | DN 50 |
| Outer pipe diameter connection 1 | 60.3mm |
| Outer pipe diameter connection 1 (imperial) | 2.37" |
| Connection 1 | Ribbing groove (groove coupling) |
| Nominal diameter connection 2 | DN 50 |
| Outer pipe diameter connection 2 | 60.3mm |
| Outer pipe diameter connection 2 (imperial) | 2.37" |
| Connection 2 | Flange |
| Main colour fitting | Grey |
| Flange standard | ANSI |
| Material sealing | Ethylene-propylene diene monomer rubber (EPDM) |
| With buffer stud | No |
| Length | 24mm |
| Length of connection 1 | 24mm |
| Length of connection 1 (imperial) | 0.94" |
| Medium temperature (continuous) | -34°C - 110°C |
| Medium temperature (continuous) (imperial) | -29.2°F - 230°F |
| With sealing rings/gaskets | No |
| Capped | No |
| With connection indicator | No |
| With drain valve | No |
| With de-aerator | No |
| FM quality mark | Yes |
| LPCB quality mark | No |
| ULC quality mark | Yes |
| UL quality mark | Yes |
| VdS quality mark | No |
| DVGW quality mark for gas | No |
| DVGW quality mark for water | No |
| Certified according to NF 545 | No |
| KIWA certified | No |
| Gastec QA mark | No |
| KOMO certified | No |
