VSH Shurjoint adapter MF 88.9xFNPT3 orange

item: 100543030001

The VSH Shurjoint Model 54 is a cast adapter that allows for a direct transition from grooved system to a female threaded system.
VSH Shurjoint grooved pipe systems consist of a wide range of groove couplings, fittings and valves for heating, compressed air and industry. VSH Shurjoint is less labor intensive, safer, cleaner and delivers consistent connection quality.
  • VSH Shurjoint can be perfectly combined with other VSH systems such as VSH XPress, VSH SudoPress and VSH PowerPress
  • the 'Aalberts integrated piping systems' range covers a fully integrated system from ¼" to 104"
read more
read less
if the download did not start automatically, click here

PDF generation failed, please try again later

applications

heating

heating

cooling

cooling

compressed air

compressed air

segments

commercial building

commercial building

industry

industry

approvals

no approvals available

label

value

label

d1

value

88.9

label

DN1

value

DN80

label

l1

value

35

label

d2

value

88.9

label

DN2

value

DN80

label

l2

value

35

label

z2

value

10

drawing for product

characteristics

color

orange

materials

cast iron (ASTM A536 65-45-12)

finishing

varnished

connection type

groove (fitting), FPT - female thread conical (NPT)

general

product group

fittings (demountable)

ETIM class

EC003024 Fitting with 2 connections

country of origin

Taiwan

brand

VSH

series

Shurjoint

type

54

product info

item

VSH Shurjoint adapter MF 88.9xFNPT3 orange

item number

100543030001

product number with GTIN

100543030001 (00670750545597)

manufacturer

Shurjoint

item group

54 - VSH Shurjoint grooved adapter (groove x female thread)

size

88.9xFNPT3 orange

weight

1 kg

dimensions

89x89x70 mm

label

value

label

Material connection 1

value

Cast iron

label

Surface protection connection 1

value

Lacquered

label

Material connection 2

value

Cast iron

label

Surface protection connection 2

value

Lacquered

label

Shape

value

Straight

label

Reducing

value

No

label

Eccentric

value

No

label

System specific

value

Yes

label

Nominal diameter connection 1

value

DN 80

label

Outer pipe diameter connection 1

value

88.9mm

label

Outer pipe diameter connection 1 (imperial)

value

3.5"

label

Connection 1

value

Groove

label

Nominal diameter connection 2

value

DN 80

label

Outer pipe diameter connection 2

value

88.9mm

label

Outer pipe diameter connection 2 (imperial)

value

3.5"

label

Connection 2

value

Internal thread conical (NPT)

label

Main colour fitting

value

Orange

label

With buffer stud

value

No

label

High tensile strength

value

Yes

label

Length

value

88.9mm

label

Length of connection 1

value

35mm

label

Length of connection 1 (imperial)

value

1.38"

label

Length of connection 2

value

35mm

label

Length of connection 2 (imperial)

value

1.38"

label

Working length connection 2

value

10.1mm

label

Working length connection 2 (imperial)

value

0.4"

label

With sealing rings/gaskets

value

No

label

Capped

value

No

label

With connection indicator

value

No

label

With drain valve

value

No

label

With de-aerator

value

No

label

FM quality mark

value

No

label

LPCB quality mark

value

No

label

ULC quality mark

value

No

label

UL quality mark

value

No

label

VdS quality mark

value

No

label

DVGW quality mark for gas

value

No

label

DVGW quality mark for water

value

No

label

Certified according to NF 545

value

No

label

KIWA certified

value

No

label

Gastec QA mark

value

No

label

KOMO certified

value

No

label

Gastec QA - AR 214 (H2)

value

No
