group: C7E
item: 100C73010002
no applications available
residential
datacenters
commercial building
industry
building installations
CRN
FM
UL
ULc
color
orange
materials
cast iron (ASTM A536 65-45-12)
finishing
varnished
manufacturer
Shurjoint
connection type
groove (coupling), MPT - male thread conical (NPT)
sealing
EPDM
product group
fittings
ETIM class
EC011014 Broaching saddle
country of origin
Taiwan
brand
VSH
series
Shurjoint
type
C7E
item
VSH Shurjoint Outlet coupling FMF 88.9xMNPT1x88.9 orange
item number
100C73010002
product number with GTIN
100C73010002 (00670750184062)
item group
C7E - VSH Shurjoint outlet coupling, EPDM gasket
size
88.9xMNPT1x88.9 orange
weight
2.8 kg
dimensions
83x175x160 mm
max operating pressure liquid
35 bar
min. medium temperature
-34 °C
max medium temperature
110 °C
label
value
label
d1
value
88.9
label
DN1
value
DN80
label
l1
value
42
label
d2
value
33.4
label
DN2
value
DN25
label
l2
value
102
label
d3
value
88.9
label
DN3
value
DN80
label
l3
value
42
label
value
label
ETIM class
label
Material
value
Cast iron
label
Material inlay
value
Ethylene-propylene diene monomer rubber (EPDM)
label
Surface protection
value
Lacquered
label
Suitable for pipe diameter
value
DN 80
label
Nominal diameter
value
DN 80
label
Outer pipe diameter
value
88.9mm
label
Outer pipe diameter (imperial)
value
3.5"
label
Max. operating pressure at 20 °C
value
35bar
label
Max. operating pressure at 20 °C (imperial)
value
507.63psi
label
Medium temperature (continuous)
value
-34°C - 110°C
label
Medium temperature (continuous) (imperial)
value
-29.2°F - 230°F
label
Width
value
83mm
label
Length of connection 1
value
41.5mm
label
Length of connection 1 (imperial)
value
1.63"
label
Length of connection 2
value
102mm
label
Length of connection 2 (imperial)
value
4.02"
label
Length of connection 3
value
41.5mm
label
Length of connection 3 (imperial)
value
1.63"
label
VdS quality mark
value
No
label
KIWA certified
value
No
label
Gastec QA mark
value
No
label
Gastec QA - AR 214 (H2)
value
No
